Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure

Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure

    • Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure
    • Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure
    • Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure
    • Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure
    • Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure
  • Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure

    Product Details:

    Place of Origin: Ningbo China
    Brand Name: Helm Tower
    Certification: ISO9001
    Model Number: Rexroth A6V

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiable
    Packaging Details: Wooden Case
    Delivery Time: 3 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 5000 pieces per month
    Contact Now
    Detailed Product Description
    Package: Wooden Case Certification: ISO9001
    Warranty: 1 Year Product Name: Hydraulic Piston Motor
    Power: Hydraulic Speed: High Speed
    Usage: Construction Machinery Color: According To Customer Demand

    Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure





    A6VM Series Rexroth Hydraulic Variable Motor And Part A6VM80 For Construction Machinery



    Features:



    Rexroth A6V hydraulic piston motor

    Large control range with hydrostatic transmission
    Cost-saving due to the possibility of using smaller pumps
    High efficient



    With hydraulic transmission, this range of variable displacement motor has wide displacement motor has wide displacement control range . It supports secondary control regulation with various control devices. It offers increased maximum output speed under reduced swivel angle conditions.

    Due to the elimincetion of gear shifts, and the possibility of using smaller pumps, the product is cost saving. Meanwhile , it offers high power density, high efficiency, good starting performance, and low moment of interia. The variable displacement motor additionally has high axial loading capacity.





    Displacement Diagram



      28 55 80 107 160 225 250 468
    Displacement Vgmax ml/r 28.1 54.8 80 107 160 225 250 468
    Vgmin ml/r 8.1 15.8 23 30.8 46 64.8 0 135
    Max.Permissible.Swept volome Qgmax L/min 133 206 268 321 424 530 590 889
    Max.speed(at Qmax) nmax at Vgmax r/min 4750 3750 3350 3000 2650 2360 2360 1900
    nmax at Vg<Vgmax r/min 6250 5000 4500 4000 3500 3100 3100 2500
    Torque constants Max at Vgmax Nm/MPa 4.463 8.701 12.75 16.97 25.41 35.71 39.79 74.41
    Max at Vgmin Nm/MPa 1.285 2.511 3.73 4.9 7.35 10.3 11.46 21.47
    Max.torque(p=35Mpa) Mmax at Vgmax Nm 156 304 446 594 889 1250 1391 2604
    Mmax at Vgmin Nm 45 8 130 171 257 360 401 751
    Max.output power(at 35Mpa and Qmax KW 78 120 156 187 247 309 335 519
    Moment Kgm2 0.0017 0.0052 0.0109 0.0167 0.0322 0.0532 0.0532 0.025
    Weight kg 18 27 39 52 74 103 103 223

    Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure

    Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure

    Large Control Range Hydraulic Wheel Motor Static Pressure Balance Structure



    Applications:


    Our motors are mainly used for construction machinery, geological drilling equipment, special vehicles,mining machinery, lifting and transporting equipment, cranes, ship machinery, agricultural and forestry machinery, and so on.
