High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50

High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50

  • High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50
  • High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50
  • High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50
  • High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50
High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50
Product Details:
Place of Origin: Ningbo
Brand Name: Helm Tower
Certification: ISO 9001
Model Number: MS18
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard Export Wooden Case
Delivery Time: 7-15 working days
Payment Terms: L/C, T/T
Supply Ability: 700 units per month
Contact Now
Detailed Product Description
Features: High Pressure Oil Seal,Low Noise Level Type: Hydraulic Engine Motor
Color: Customized Speed: 0-150 R/min
Torque: 5212-7843 N.m Rated Pressure: 25 MPa
Max. Pressure: 31.5 MPa Suit For: Construction & Mining
Torque Range: 13077-22463 N. M Max Pressure: 31.5 MPa
Oil Temperature: Normal-35℃-80℃
High Light:

MS18-2-111-F12-2A50 Hydraulic Drive Motor

,

MS Series Hydraulic Drive Motor

,

Low Speed Hydraulic Drive Motor

High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50

High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50 0

High Pressure Low Speed Hydraulic Drive Motor MS Series MS18-2-111-F12-2A50 1



MS Series Hydraulic Motor is one kind of low speed high torque radial piston motor with advanced design in disc distribution flow, piston structure, high pressure rating, smooth running at very low speeds, available with different valves, brakes.





Type MS18-8 MS18-9 MS18-0 MS18-1 MS18-2
Displacement(ml/r) Full Semi Full Semi Full Semi Full Semi Full Semi
1395 697 1571 785 1747 873 1911 955 2099 1049
Max power(kw) 62 42 62 42 62 42 62 42 62 42

Pressure discrepancy

10MPa Torque (N. m)

2085 1022 2348 1151 2611 1279 2856 1400 3137 1537
Rated torque(N. m) 5212 5870 6528 7140 7843
Rated pressure(MPa) 25 25 25 25 25
Max pressure(MPa) 40 40 40 35 35
Rated speed(r/min) 55 55 55 55 50
Speed range(r/min) 0-150 0-150 0-150 0-135 0-125



Our advantages:

1).High performance:our motor performance is very close to Poclain original motors, even sometimes be superior to original motor.

2).100% interchangeable:both complete motor and spare parts, our products could completely replace to Poclain original motors.

3).Reasonable price:our price system has been settled much lower than Poclain original motors.

4).Fast delivery time:most of the spare parts we have inventory, the delivery time keeps within 10 days for regular motor.

5).Excellent aftersales service:we have 12 months' quality warranty, and within warranty time ,all repairment are free of charge.

Applications:

Construction: road building and maintenance, earth moving, finishing, drilling, trenching, recycling, mining and boring machines.

Agriculture: combine and others specialty harvesters, sprayers, forestry equipment,

Handling: forklift trucks, aerial work platforms, conveyors, aircraft loading equipment,

Industry: process, paper, foundry, food.

Marines: fishing, harbor,

Transportation: material, heavy duty, on-highway.
