High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter

High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter

  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
  • High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter
Product Details:
Place of Origin: Ningbo China
Brand Name: Helm Tower
Model Number: Marine Hydraulic winch
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Wooden Case
Delivery Time: 3 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 piece per month
Contact Now
Detailed Product Description
Certification: ISO9001 Type: Professional Lifting Equipment Cable Electric Winch
Color: Customer Requirement Warranty: 1 Year
Package: Wooden Case Material: Steel
Delivery Time: 1-3 Days MOQ: 1 Set
High Light:

hydraulic powered winch

,

heavy duty hydraulic winch

High Starting Efficiency Industrial Hydraulic Winch For Fishing Runva Log Splitter



Features:



0-5T/ 10T/ 15T/ 20T/25T/30T Hydraulic winch
With Hydraulic Motor, Gearbox, Brake, Valve, Baseplate, etc;
Capacity 0-5T/ 10T/ 15T/ 20T/ 30T, etc;
Cable diameter 20MM/ 28MM/ 32MM, etc;
Cable lenth 50M/ 100M/ 300M/ 500M, etc;
Speed 40/ 20/ 10MPM, etc;
Working pressure 30MPa/ 25MPa/ 20Mpa/ 16.3Mpa, etc

High starting and working efficiency, Low energy consuming,

Low noise, Compact size.



By the way, we also can offer the UMC and NABRICA original manual winch, made in china.



Hydraulic winch is made up of hydraulic motor, multi-disc friction brake, planet gearbox decelerator, spool and bracket as a whole. There are shuttle valve and balance valve in the lifting weight from dropping also it can keep loading and unloading stable. Stepless speed, high starting efficiency, reliable, easy to install and control. Widely applied in all kinds of cane for railway transport, shipping, mining, port, etc.



Pulling force

(Kgf)

Displacement(ml/l)

Lifting pressure

(MPa)

Lifting speed

(m/min)

Diameter of wire

(mm)

Plies

Rope capacity

(m)

Weight

(kg)

1000 700 16 48-60 10 4 70 100
1500 1078 16 32-40 10 4 70 100
2000 1500 16 25-27 12 4 100 100
3000 2100 16 18-20 14 4 90 100
4000 2800 16 19-22 15 4 85 150
5000 3990 16 14-16 16 4 100 200
6000 5600 16 18-20 18 4 100 200
7000 6110 16 16-18 18 4 100 300
8000 6909 16 14-16 20 4 100 300
10000 7550 16 16-18 24 4 120 300
11000 11500 16 14-16 24 4 120 450
12000 12712 16 12-14 26 4 100 450
13000 14050 16 14--16 26 4 100 450



QQ20130620165613.jpgQQ20130620165621.jpgQQ20130620165629.jpgQQ20130620165638.jpgQQ20130620165642.jpg



2. Applications:

Our winches are mainly used for many kinds of cranes, ship machinery and so on.
For more details, pls go to our website: http://www.hydraulics-china.com/
